Nuclear Projects

We have completed a number of gas turbine control systems retrofits at nuclear power stations. These include:

  • Pickering B standby generators, six Orenda gas turbines.
  • Bruce B standby generators, four RR Avon gas turbines.

These projects have involved design manufacture and testing to demanding quality control procedures, including:

  • Implementation and maintenance of design and supply quality control to Z299.2.
  • Implementation of software quality assurance (SQA) procedures to satisfy the requirements of the CANDU, OASES standards for software production.

More details of these projects can be found on Project Examples. We have the experience and proven QA systems to respond to the requirements of a nuclear operator and provide a high quality fully documented system.

Quality Assurance

Nuclear Quality Assurance Procedures

The projects that have been completed on nuclear plant have involved strict implementation of rigorous and robust quality assurance programs.

  1. Implementation and maintenance of design and supply quality control to Z299.2.
  2. Implementation of software quality assurance (SQA) procedures to satisfy the requirements of the AECL CANDU standards for software production.

CSA Z299.2 Quality Assurance Program

The Z229.2 quality control standards cover the design, supply and testing of the company's products. Key elements include:

  1. Management responsibilities
  2. Quality Manual
  3. Tender and contract
  4. Design
  5. Documentation control, internal and external
  6. Procurement
  7. Inspection, test and control of test equipment
  8. Incoming and final inspection
  9. Identification and traceability
  10. Handling and storage
  11. Production
  12. Packing and shipping
  13. Non-conformance and corrective action
  14. Customer supplied items
  15. Quality audits

We were previously qualified to BS EN ISO 9001:2000. A GAP analysis was performed which resulted in a number of changes to the ISO procedures to cover the requirements of Z229.2. These procedures were then audited by OPG to ensure compliance.

Software Quality Assurance

This included the production of key software specifications and test procedures to ensure compliance with these specifications:

  1. Software development plan.
  2. Computer system requirements (CSR) - To define what the software must do.
  3. Computer system design (CSD) - How the hardware and the software of the computer system will be design to meet the requirements.
  4. Software requirements specification (SRS) - To define how the computer system will be programmed to meet the requirements.
  5. Sub-system test procedures - Testing to ensure compliance with the SRS.
  6. System integration test - Testing to ensure compliance with the CSD.
  7. Factory acceptance test procedure - Testing to ensure compliance with the CSR.
  8. Site static and dynamic test procedures.

SMARTStart Quality Assurance

Seismic Testing:

Triaxial seismic qualification test programme in accordance with IEEE 344-2013, Recommended Practice for Seismic Qualification of Class 1E Equipment for Nuclear Power Generating Stations.

EMC Tests:
  • Emissions:
    • CISPR 16-2-3:2006 – Radiated Emissions
    • CISPR 16-2-1:2008 – Conducted Emissions
    • CISPR 22:2008 – Telecommunication Ports Common Mode Emissions
  • Temperature tests:
    • Low Temperature
      • In accordance with BS EN 60068-2-1, Low Temperature.
      • Operation of equipment at -5°C
    • High Temperature
      • In accordance with BS EN 60068 2-2 test Bd.
      • Operation of equipment at 55°C
  • Immunity:
    • EN 61000-4-2:2009 – Electrostatic Discharge Immunity
    • EN 61000-4-3:2006 +A1:2008 +A2:2010 – Radiated RF Immunity
    • EN 61000-4-4:2012 – Electrical Fast Transients Immunity
    • EN 61000-4-5:2014 – Voltage Surge Immunity
    • EN 61000-4-6:2014 – Conducted RF ImmunityM
    • EN 61000-4-8:2010 – Power Frequency Magnetic Field Immunity
    • EN 61000-4-9: 1993 + A1:2001 – Pulse Magnetic Field Immunity
    • EN 61000-4-11:2004 – Voltage Dips and Short Interruptions Immunity
    • EN 61000-4-16:1998 + A2:2011 Conducted Common Mode Disturbances Immunity
